ABB 500PSM03A 1MRB150038R1 Power Supply Module

ABB 500PSM03A 1MRB150038R1 is a rack power supply module for ABB AC800M control system. It converts the input mains power into stable DC power to supply the CPU, communication modules and I/O boards installed in the same control rack.

This module features overvoltage, overcurrent and short-circuit protection, plus built-in power status monitoring and fault alarm functions. It is rack-mounted and widely used for power plant DCS cabinet maintenance, spare replacement and automation system renovation projects.

Data Parameters

• 1. Brand: ABB.

• 2. Model: 500PSM03A, Part Number:1MRB150038R1.

• 3. Product Type: Rack Power Supply Module.

• 4. Product Series: AC800M Controller System.

• 5. Function: Provide stable DC power for rack modules.

• 6. Protection: Overvoltage, overcurrent and short circuit protection.

• 7. Monitoring: Power status detection and fault alarm output.

• 8. Bus: Rack backplane power distribution.

• 9. Mounting: Standard control rack installation.

• 10. Operating Temperature: 0℃ ~ +60℃.

Core Functions

• 1. Convert input AC power to regulated DC power to feed AC800M rack CPU, CIM, BIO and I/O modules.

• 2. Built-in multi-layer protection against overvoltage, overload and short circuit to protect expensive control hardware.

• 3. Real-time monitor output voltage and current, send power failure or abnormal power alarms to controller.

• 4. Support hot standby redundant power configuration to improve the continuous running reliability of control rack.

• 5. Seamless integration into AC800M rack, working together with 500CPU05,500CIM05 and 500BIO01 modules.

Application Scenarios

• 1. Thermal power plant AC800M control rack power supply spare replacement.

• 2. Metallurgy industry distributed automation control cabinet power system upgrade project.

• 3. Pulp and paper factory continuous process control cabinet spare renewal.

• 4. Process industry AC800M control system spare inventory backup.

• 5. Legacy ABB AC800M system aging power supply module replacement project.

FAQ

• 1. Q: What is ABB 500PSM03A 1MRB150038R1?
      A: It is ABB AC800M rack power supply module, supplying DC power for all modules inside the control rack.

• 2. Q: Can it work in redundant configuration?
      A: Yes, two modules can be installed as redundant power supply to avoid shutdown caused by single power failure.

• 3. Q: Can it be hot swapped?
      A: Redundant configuration supports hot swap; cut off power supply before removing module for non-redundant rack.
