ALSTOM 12004-101-01 SBS Serial Bus Baseplate

ALSTOM 12004-101-01 is an SBS serial bus baseplate for Alstom turbine control system. It acts as the carrier rack to install SBS series I/O modules, distributing 24V DC power and proprietary serial bus signals between main controller and individual I/O cards.

This baseplate adopts RS485 physical layer for SBS bus communication, and provides galvanic isolation to protect circuits from high electromagnetic interference in power plant environment. It supports hot swapping of plug-in I/O modules, widely used as spare replacement for turbine control cabinet maintenance and retrofit projects.

Data Parameters

• 1. Brand: ALSTOM.

• 2. Model: 12004-101-01.

• 3. Product Type: SBS Serial Bus Baseplate.

• 4. Nominal Power Supply: 24V DC, operating range 18~36V DC.

• 5. Bus Type: ALSTOM proprietary SBS serial bus, RS485 physical layer.

• 6. Isolation Rating: 2000VAC isolation between bus and field signal circuit.

• 7. Operating Temperature: -10℃ ~ +70℃.

• 8. Mounting: Standard DIN rail or cabinet rack installation.

• 9. Feature: Support hot swap of individual SBS I/O modules.

• 10. Compatible System: ALSTOM steam and gas turbine control SBS I/O system.

Core Functions

• 1. Serve as the mechanical carrier for installing multiple SBS series digital and analog I/O modules.

• 2. Distribute 24V DC power supply and SBS serial bus signals to each plugged I/O module.

• 3. Realize bidirectional data transmission between turbine main controller and all I/O modules on the baseplate.

• 4. Provide electrical isolation to reduce electromagnetic interference and avoid ground loop faults.

• 5. Allow replacing individual I/O boards without powering down the entire turbine control rack.

Application Scenarios

• 1. Thermal power plant ALSTOM turbine control cabinet baseplate replacement and maintenance.

• 2. Gas turbine safety protection system SBS I/O rack retrofit and spare upgrade.

• 3. Power generation industry distributed I/O expansion for turbine control system.

• 4. Petrochemical plant turbine automation system spare parts inventory backup.

• 5. Legacy ALSTOM SBS series control hardware overhaul and renewal project.

FAQ

• 1. Q: What is ALSTOM 12004-101-01?
      A: It is SBS serial bus baseplate designed for ALSTOM turbine control system, used to carry SBS I/O modules.

• 2. Q: What is SBS bus?
      A: It is ALSTOM proprietary serial bus based on RS485 physical layer for communication between turbine controller and I/O modules.

• 3. Q: Can I swap I/O modules on this baseplate online?
      A: Yes, the baseplate supports hot swap of individual I/O cards without shutting down the whole rack.
