Bently Nevada 3500/15 125840-02 Dual Power Supply Module

Bently Nevada 3500/15 125840-02 is a redundant dual power supply module designed for the Bently Nevada 3500 machinery monitoring rack. It supplies stable DC power to all installed monitoring modules, supporting redundant power input to guarantee continuous operation for critical rotating machinery protection systems.

This power module supports hot swap and built-in power fault diagnostic alarms. It can accept AC or DC input options and automatically switch between dual power paths in case of one source failure, widely used for vibration monitoring cabinet maintenance, spare parts replacement and machine protection system retrofit projects.

Data Parameters

• 1. Brand: Bently Nevada (Baker Hughes).

• 2. Model: 3500/15, Part Number:125840-02.

• 3. Product Type: Redundant Dual Power Supply Module.

• 4. Product Series: 3500 Machinery Protection System.

• 5. Input: Wide range AC/DC power input.

• 6. Output: Regulated internal rack DC power for 3500 modules.

• 7. Redundancy: Dual redundant power path with automatic failover.

• 8. Feature: Hot swappable without system shutdown.

• 9. Diagnosis: Built-in undervoltage, overvoltage and fault detection.

• 10. Operating Temperature: 0℃ ~ +60℃.

Core Functions

• 1. Convert external AC/DC input into stable DC power to feed all modules inside the 3500 rack.

• 2. Dual redundant power design, automatic switchover if one power source fails to avoid system outage.

• 3. Continuously monitor power status and trigger alarm signals for abnormal voltage or hardware faults.

• 4. Support hot-swap replacement, allowing maintenance without stopping machinery monitoring system.

• 5. Deliver reliable power supply for turbine, compressor and pump vibration & position monitoring modules.

Application Scenarios

• 1. Thermal power plant turbine monitoring cabinet power supply spare parts replacement and maintenance.

• 2. Oil & gas compressor critical rotating machinery protection system upgrade project.

• 3. Petrochemical plant large equipment online vibration monitoring system spare parts renewal.

• 4. Steel, paper and mining factories critical machine protection system backup inventory.

• 5. Legacy Bently Nevada 3500 machinery monitoring system aging power module replacement project.

FAQ

• 1. Q: What is Bently Nevada 3500/15 125840-02?
      A: It is redundant dual power supply module for Bently Nevada 3500 machinery protection monitoring rack.

• 2. Q: What is the advantage of dual redundant power?
      A: If one power path fails, the system automatically switches to the other path without interruption of monitoring.

• 3. Q: Can the module be hot swapped?
      A: Yes, it supports hot swap, module replacement will not shut down the whole 3500 monitoring rack.
