ABB 5SHY4045L0006 3BHB030310R0001 IGCT Power Semiconductor Module in stock
ABB 5SHY4045L0006 (Order No:3BHB030310R0001) is an asymmetric integrated gate-commutated thyristor (A-IGCT) power module. It adopts press-pack packaging with double-sided cooling, designed for high-power medium voltage drive and power conversion systems.
This high-power semiconductor device features fast switching speed and high reliability. It is widely used in ABB ACS6000 medium voltage inverters, metallurgical main drives and power transmission projects, serving as core spare parts for high-power power electronic equipment.
Main Specifications
| No. | Item | Parameter |
|---|---|---|
| 1 | Brand | ABB |
| 2 | Model | 5SHY4045L0006, Order No:3BHB030310R0001 |
| 3 | Module Type | A-IGCT Integrated Gate Commutated Thyristor |
| 4 | Rated Voltage | 4500V |
| 5 | Rated Current | 4000A |
| 6 | Packaging | Press-pack, double-sided liquid cooling |
| 7 | Gate Drive | Match with GVC750BE101 gate driver unit |
| 8 | Application Platform | ACS6000 medium voltage inverter power unit |
Core Functions
| No. | Function Description |
|---|---|
| 1 | Act as high-speed power switch for medium voltage frequency converter, realize AC-DC-AC energy conversion |
| 2 | Support high current and high voltage operation, control power output for large motor speed regulation |
| 3 | Press-pack structure provides good thermal conductivity and high tolerance for thermal cycling and vibration |
| 4 | Fast turn-off characteristic, cooperate with gate driver to realize short-circuit protection within microseconds |
| 5 | Core power component for high-power transmission, energy conversion and power quality control equipment |
Application Scenarios
| No. | Application |
|---|---|
| 1 | Metallurgy rolling mill main drive, mine hoist medium voltage frequency conversion system |
| 2 | Oil & gas offshore platform large motor drive and power conversion equipment |
| 3 | Cement, chemical industry high-power medium voltage inverter power unit |
| 4 | Power plant power transmission, static var compensator and HVDC converter valve |
| 5 | ACS6000 inverter overhaul, power module replacement and spare parts inventory |
FAQ
| No. | Question & Answer |
|---|---|
| 1 | Q:What is ABB 5SHY4045L0006? A:It is ABB 4500V 4000A A-IGCT press-pack power semiconductor module, widely used in ACS6000 medium voltage drive power units. |
| 2 | Q:What cooling method does it require? A:Double-sided liquid cooling with deionized water/glycol coolant, stable cooling flow required during operation. |
| 3 | Q:What drive board matches this IGCT? A:Mainly paired with GVC750BE101 gate driver board for gate trigger and protection control. |
