ABB XUD194 3BHC018137R0001 Excitation Hybrid I/O Module in stock

ABB XUD194 3BHC018137R0001 is a hybrid input and output module based on the AC800PEC platform for ABB UNITROL generator excitation system. It integrates analog and digital signal acquisition and output functions, responsible for collecting PT/CT signals and sending pulse commands to the power unit.

This module adopts high-density connector design and high-voltage isolation circuit between control and power sides. It supports fast closed-loop AVR regulation and built-in fault diagnosis, widely used for excitation cabinet renovation and spare replacement of synchronous generators in power plants.

Data Parameters

• 1. Brand: ABB.

• 2. Model: XUD194 3BHC018137R0001.

• 3. Product Type: Excitation Hybrid I/O Module.

• 4. Application: UNITROL Excitation System, AC800PEC Platform.

• 5. Feature: Mixed analog & digital I/O, high voltage isolation design.

• 6. Characteristic: High EMC performance, comprehensive self-diagnosis function.

• 7. Communication: Internal high-speed control bus, Ethernet interface.

• 8. Package: Original rack module assembly.

• 9. Mounting: Rack installation inside excitation control cabinet.

• 10. Operating Temperature: -25℃ ~ +70℃.

Core Functions

• 1. Collect generator voltage, current and switch status signals on site.

• 2. Execute automatic voltage regulation and reactive power control logic.

• 3. Output trigger pulses to drive thyristor rectifier power unit.

• 4. Detect circuit faults such as overvoltage, overcurrent and open circuit.

• 5. Upload real-time operating data and alarm information to DCS system.

Application Scenarios

• 1. Thermal power and hydropower station synchronous generator excitation cabinet.

• 2. Self-provided power plant generator set voltage regulation control system.

• 3. ABB UNITROL excitation system upgrade, commissioning and spare replacement.

• 4. Grid-connected generator stability control and reactive power adjustment.

• 5. Power industry excitation control spare parts inventory backup.

FAQ

• 1. Q: What is ABB XUD194 3BHC018137R0001?
      A: It is a hybrid I/O module for ABB UNITROL generator excitation system.

• 2. Q: Which control platform does it belong to?
      A: It works based on ABB AC800PEC high-performance control platform.

• 3. Q: Can it realize AVR automatic voltage regulation?
      A: Yes, it supports closed-loop AVR regulation and reactive power adjustment.
