GE IS220PRTDH1B RTD Temperature Input I/O Pack in stock

GE IS220PRTDH1B is a dedicated RTD input I/O pack for GE Speedtronic Mark VIe and Mark VIeS turbine control systems. It works with TRTD terminal boards to collect resistance signals from Pt100, Pt1000 and other RTD sensors, converting raw resistance data into digital temperature values and transmitting to the main controller via dual IONet Ethernet ports.

This pack supports 3-wire RTD connection, built-in high-precision signal conditioning and channel diagnostic function. It supports simplex and TMR redundant configurations, widely used for bearing temperature, stator winding temperature monitoring of gas turbines, steam turbines and generators, and is a common spare part for power plant Mark VIe cabinet maintenance.

Data Parameters

• 1. Brand: GE (General Electric, Speedtronic)

• 2. Model: IS220PRTDH1B

• 3. Product Type: RTD Temperature Input I/O Pack

• 4. Application: Mark VIe / Mark VIeS turbine and generator temperature monitoring system

• 5. Feature: Dual Ethernet, high-precision measurement, open/short circuit fault detection, TMR compatible

• 6. Characteristic: Modular I/O pack, hot swap capable, rugged industrial housing

• 7. Supported Sensor: Pt100, Pt1000, Ni RTD, 3-wire configuration

• 8. Matching Terminal Board: IS200TRTDH series RTD terminal board

• 9. Mounting: Plug-in installation inside Mark VIe I/O rack

• 10. Operating Temperature: -30℃ ~ +65℃

Core Functions

• 1. Supply constant excitation current to field RTD temperature sensors.

• 2. Collect resistance signals and calculate accurate temperature values internally.

• 3. Detect open circuit, short circuit and abnormal wiring for each RTD channel.

• 4. Communicate temperature data and fault status to controller through redundant IONet network.

• 5. Provide temperature data for turbine over-temperature alarm and protection logic.

Application Scenarios

• 1. Combined cycle power plant gas turbine bearing temperature monitoring cabinet.

• 2. Steam turbine and generator stator winding temperature measurement rack.

• 3. GE Mark VIe turbine control system overhaul and spare replacement.

• 4. Auxiliary equipment and boiler thermal monitoring signal acquisition unit.

• 5. TMR redundant safety temperature protection loop for power generation units.

FAQ

• 1. Q: What is GE IS220PRTDH1B?
      A: It is an RTD input I/O pack for Mark VIe system, used to acquire and process temperature signals from RTD sensors.

• 2. Q: What is the difference between IS220PRTDH1B and IS200TRTDH1DCB?
      A: PRTDH1B is the I/O processor pack, TRTDH1DCB is the field terminal board, they must work together.

• 3. Q: Does it support hot swap?
      A: Yes, it supports hot swapping under proper maintenance procedure without shutting down the whole rack.
