CISCO IE-2000-8TC-G-B Ethernet Switch in stock

CISCO IE-2000-8TC-G-B is a rugged industrial managed switch from Cisco IE2000 series. It is equipped with 8×10/100Base-TX downlink ports and 2×Gigabit combo uplink ports, supporting LAN Base image, designed for factory automation, energy and transportation industrial network environments with wide temperature tolerance and anti-interference capability.

This fanless DIN-rail mount switch supports dual redundant DC power input. It delivers reliable layer 2 switching, VLAN, QoS and ring protection functions, widely used for connecting field sensors, PLCs and industrial controllers, it is a common spare for industrial network renovation and maintenance.

Data Parameters

• 1. Brand: Cisco

• 2. Model: IE-2000-8TC-G-B

• 3. Product Type: Industrial Managed Ethernet Switch

• 4. Application: Factory automation, power, oil & gas, transportation industrial network

• 5. Feature: 8 FE copper ports, 2 GE combo uplink (RJ45/SFP), LAN Base

• 6. Characteristic: Fanless cooling, DIN rail mounting, wide temperature range

• 7. Switching Capacity: 7.6 Gbps, Forwarding rate: 5.66 Mpps

• 8. MAC Address Table: 8000 entries, Max 1005 VLANs

• 9. Power Supply: Dual 9.6–60VDC redundant input

• 10. Operating Temperature: -40℃ ~ +75℃

Core Functions

• 1. Realize stable data exchange between PLC, sensor and upper industrial control host.

• 2. Support industrial ring redundancy, rapid link recovery to avoid network interruption.

• 3. Provide VLAN division, QoS priority scheduling and access security control.

• 4. Support dual power redundancy, automatic switchover when one power source fails.

• 5. Fanless design adapts to dusty, vibration and high EMI industrial sites.

Application Scenarios

• 1. Automobile production line and automated workshop field control network cabinet.

• 2. Power plant, substation and petrochemical plant industrial communication system.

• 3. Railway, tunnel and transportation harsh environment data acquisition network.

• 4. Cisco IE2000 series industrial switch overhaul and spare replacement.

• 5. Field bus and EtherNet/IP, Modbus TCP industrial network access layer.

FAQ

• 1. Q: What is CISCO IE-2000-8TC-G-B?
      A: It is Cisco IE2000 series industrial managed switch with 8 FE ports and 2 Gigabit combo uplink ports.

• 2. Q: What does “G” in the model mean?
      A: G means Gigabit uplink, B represents LAN Base software license.

• 3. Q: Does it support PoE?
      A: This model does not support PoE power supply function.
