EATON CS-TX3-3.81X2.54-64TW Pluggable PCB Terminal Block Connector in stock

EATON CS-TX3-3.81X2.54-64TW is a high-density pluggable PCB terminal block connector designed for industrial automation control boards. It adopts cage clamp screw connection technology to realize reliable wiring and signal transmission for multi-channel I/O signals.

This terminal block features dual pitch design of 3.81mm horizontal and 2.54mm vertical, supporting compact PCB installation. It is widely used as spare wiring accessories for PLC, DCS, motion control and industrial machinery control cabinets.

Data Parameters

• 1. Brand: EATON.

• 2. Model: CS-TX3-3.81X2.54-64TW.

• 3. Product Type: Pluggable PCB Mount Terminal Block Connector.

• 4. Number of Positions: 64 positions.

• 5. Horizontal Pitch: 3.81 mm.

• 6. Vertical PCB Pin Pitch: 2.54 mm.

• 7. Rated Voltage: 300 V.

• 8. Rated Current: Up to 10 A per channel.

• 9. Wire Gauge Range: 0.08 ~ 4.0 mm² (28-12 AWG).

• 10. Operating Temperature: -40℃ ~ +105℃.

Core Functions

• 1. Provides high-density multi-channel signal wiring connection for industrial control PCB boards.

• 2. Uses cage clamp screw technology to guarantee stable and vibration-resistant wire connection.

• 3. Supports pluggable structure for fast disassembly, maintenance and module replacement.

• 4. Transmits digital input, output and analog signals between control boards and field devices.

• 5. PA housing with UL94 V-0 flame retardant property for industrial safety protection.

Application Scenarios

• 1. PLC and DCS control cabinet signal wiring terminals.

• 2. Industrial motion controller and servo drive interface connection.

• 3. Semiconductor equipment and automated production machinery control boards.

• 4. Power plant and petrochemical field signal acquisition modules.

• 5. PCB board wiring renovation and spare connector replacement projects.

FAQ

• 1. Q: What is EATON CS-TX3-3.81X2.54-64TW used for?
      A: It is a 64-position pluggable PCB terminal block, used for high-density signal wiring on industrial control PCBs for PLC, DCS and automation equipment.

• 2. Q: What is the pitch specification of this terminal block?
      A: Horizontal terminal pitch is 3.81mm, vertical PCB pin header pitch is standard 2.54mm.

• 3. Q: What is the maximum rated current per channel?
      A: Each channel supports up to 10A, subject to wire size and working environmental conditions.
