Triconex 4200 Remote Extender Module (RXM) in stock

Triconex 4200 is a Remote Extender Module for Triconex Tricon TMR safety instrumented system(SIS). It adopts single-mode fiber to realize long-distance communication between the main controller rack and remote I/O chassis, separating control hardware geographically while maintaining triple redundant safety data transmission.

This module supports up to 15km fiber transmission distance, with built-in optical link and hardware diagnostic functions. It adopts TMR triple modular redundancy architecture and supports hot-swap replacement, widely used for ESD, FGS safety cabinet transformation, spare parts replacement and distributed safety interlock projects.

Data Parameters

• 1. Brand: Triconex (Schneider Electric).

• 2. Model: 4200.

• 3. Product Type: Remote Extender Module (RXM).

• 4. Product Series: Tricon Safety Instrumented System.

• 5. Medium: Single-mode optical fiber.

• 6. Max Transmission Distance: 15 km.

• 7. Architecture: Triple Modular Redundancy (TMR).

• 8. Feature: Hot swappable without system shutdown.

• 9. Diagnosis: Optical link and module hardware fault detection.

• 10. Operating Temperature: 0℃ ~ +60℃.

Core Functions

• 1. Establish long-distance redundant fiber link between Tricon main rack and remote I/O chassis.

• 2. Transmit TMR safety I/O data, maintain triple voting mechanism between remote I/O and main CPU.

• 3. Continuously monitor optical signal quality and module status, report communication or hardware faults.

• 4. Realize distributed layout of safety I/O, no need to deploy independent SIS controller at remote field area.

• 5. Support hot-swap replacement for online maintenance without interrupting the whole safety protection system.

Application Scenarios

• 1. Oil & gas plant long-distance distributed ESD emergency shutdown system spare replacement.

• 2. Petrochemical cross-area fire & gas safety monitoring remote I/O extension upgrade project.

• 3. Power plant large unit safety interlock system remote chassis fiber communication renewal.

• 4. Refining and chemical factories SIL3 safety instrumented system spare inventory backup.

• 5. Legacy Triconex Tricon safety system aging remote extender module replacement project.

FAQ

• 1. Q: What is Triconex 4200?
      A: It is single-mode fiber remote extender module for Tricon SIS, used for long-distance connection between main rack and remote I/O chassis.

• 2. Q: What is the difference between 4200 and 4210?
      A: 4200 uses single-mode fiber with max 15km distance, while 4210 is multi-mode fiber type limited within 2km.

• 3. Q: Can 4200 be hot swapped?
      A: Yes, it supports hot swap, module replacement will not shut down the whole Tricon safety system.
